2026 QUAD 4 ROWS OF 8 FULL AXLE WIDENING LOW LOADER WITH HYDRAULIC SUSPENSION
New build For sale Low Loaders

2026 QUAD 4 ROWS OF 8 FULL AXLE WIDENING LOW LOADER WITH HYDRAULIC SUSPENSION

Haulmore · 2026 · Price on application

Quad full-axle widening low loader, 120,000 kg design rating, hydraulic suspension

120,000kgs 130,000kgs 70,000kgs 21,260kgs Pressure gauges fitted to register axle loads Double acting hydraulic Fitted to suit 2x 20’-0” or 1x 40’-0” 60 litre aluminium fitted To comply with ADR 4 only on bull worn 5 fitted, two dunnage trays Both sides To all bare metal surfaces Primed and painted with two pack enamel Red and white coamings Painted in your fleet colours QUAD FULL SUSPENSION WIDENER – LOW LOADER – PRICE ON APPLICATION 43 kgs 12125mm CLOSED – 2500mm – OPEN – 3500mm approx – 15,500 kgs approx. 34000kgs, subject to correct weight distribution Bi-Fold Ramps Stress Relieved Skid Plate Two King Pin Positions, Removable King Pin Four Tyre Carriers, Two on Gooseneck-Two Under Frame Seven Tool Boxes Lombardini Diesel Power Pack Revolving Lamp Oversize Signs Pressure/Load Sensing Gauges Hydraulic Raise Axle to Front and Rear Axles Access Steps Both Sides at the Front of the Deck

Get a quote

FOOTAGESee it work

PRECISION VIEWERInspect this build

Precision ViewerOrbit, pan and inspect the 2026 QUAD 4 ROWS OF 8 FULL AXLE WIDENING LOW LOADER WITH HYDRAULIC SUSPENSION from every angle.
  • DESIGN RATING —
  • AGG MASS —
  • SUSPENSION —
  • AXLE CONFIG quad (4 rows of 8)

TELEMETRYFull specification

Dimensions

Deck length13 metres
Deck widthClosed 2700mm / Open 4500mm
Deck height950mm

Running Gear

Stud count10 stud
PCD225 PCD
Axle makeK HITCH
Axle configurationquad (4 rows of 8)
Axle count4

Braking & Electrical

Brake systemDrum brake

Compliance

Brake/ADR complianceADR38/05
Data-quality note
  • "Details" section on source repeats a different trailer's spec (design rating 43 kgs, deck length 12125mm) conflicting with the main Specification (design rating 120,000kgs, deck length 13m) — main Specification values used

We surface contradictions in the source data rather than silently picking — confirm the final figure with our team.

BUILD FEATURESEngineered in

  • 120,000kgs
  • 130,000kgs
  • 70,000kgs
  • 21,260kgs
  • Fitted to suit 2x 20’-0” or 1x 40’-0”
  • 60 litre aluminium fitted
  • 4 only on bull worn
  • 5 fitted, two dunnage trays

DEPLOYMENTBuilt for

Heavy machinery transportOversize plant haulage
